Item#: 010907S
Price: $4.19 ea.
|
9mm flat FDA Silicone suction cup
General Specifications
Style: Flat
Cleats: No
Material: Silicone
Thread Size: None
Outside Diameter: 9.0mm
Weight(lbs): 0.0002
Color: Translucent
Lifting Capacity: See Chart [X] CloseLifting Capacity for Item 010907S
| Level of Vacuum (inHg) |
Horizontal |
Vertical |
| 6"Hg |
0.11 lbs. |
0.05 lbs. |
| 18"Hg |
0.35 lbs. |
0.17 lbs. |
| 27"Hg |
0.53 lbs. |
0.26 lbs. |
***Disclaimer: Lifting capacity for handling a non-porous surface. Figures are theoretical and based on 80% of suction cup outside diameter with a 2:1 safety margin for horizontal lifting and a 4:1 safety margin for vertical lifting.
Includes fitting?: NO
 Recommended replacement for: VPU8SI, VU8-WS, 3150116S, 102.009.092.2, XP-U8S, U8.20 |
|
|
|
